AAAC

Specification
SPLN 41-10 : 1993

Classification
Low Voltage

Application
Bundle Conductor for Overhead Distribution Network with or without Public Lighting (between Pole to Pole)

Construction
Conductor
- NF2X: Stranded Copper Conductor
- NFA2X: Stranded All Aluminium Conductor

Insulation
Extruded of XLPE, capable for continuous operation at maximum cable's temperature.

Download Full Specs Here :

All Alumunium Alloy Conductor, XLPE Insulated

All Aluminum Alloy Conductor , XLPE Covered
Ref. Standard   :  SPLN 41-10

Construction    :

1. Aluminum Conductor
2. XLPE Insulated

Size range         : 35 ~ 240 mm²

Application       : For Used in medium voltage, Overhead line.

Download Full Specs Here :

CV

Copper Conductor , XLPE/PE insulation and PVC Outer Sheathed
Ref. Standard             :  JIS C 3606

Construction              :

1. Copper Conductor
2. XLPE/PE Insulation
3. PVC Outer Sheath

Size range                   :

1 x (2.5 ~ 500) mm²
2 x (2.5 ~ 300) mm²
3 x (2.5 ~ 300) mm²
4 x (2.5 ~300) mm²
5-9 x (2.5 ~ 16) mm²
10-30 x (2.5~10)mm²

Application                :

Indoor, Induct installationor for laying in the ground where no mechanical damage sustained

Download Full Specs Here :

NYA

Copper  Conductor and PVC Insulated

Ref. Standard         :

SNI 04-6629.3
SPLN 42-1

Construction        :

1. Copper Conductor
2. PVC Insulation

Size range             :

1.5 ~ 500 mm²

Application            :

Permanent installation in conduit or exposed wiring in dry location

Download Full Specs Here :

NYFGBY

Copper Conductor, PVC Insulated, Galvanized flat steel wire and  Steel  tape binder and PVC Outer Sheathed.

Ref. Standard              :

SNI IEC 60502-1
SPLN 43-2

Construction               :

1. Copper Conductor
2. PVC Insulation
3. PVC Inner Sheathed
4. Galvanized flat steel wire and Steel tape binder
5.  PVC Outer sheathed

Size range                    :

2 x (1.5~300) mm²
3 x (1.5~240) mm²
4 x (1.5~300) mm²
5 x (1.5~50)mm²
7-61 core

Application                  :

Indoor and outdoor installation , direct burial preferable used where considerable mechanical strees must be envisaged

Download Full Specs Here :

NYM

Copper conductor, PVC insulated and PVC Outer Sheathed

Ref. Standard                :

SNI 04-6629-4
SPLN 42-6-2

Construction                 :

1. Copper Conductor
2. PVC Insulated
3. PVC Inner sheathed
4. PVC Outer sheathed

Size range                     :

2 x (1.5~35) mm²
3 x (1.5~35) mm²
4 x (1.5~35) mm²
5 x (1.5~35)mm²

Application                   :

Permanent installation in conduit under plester or exposed installation in dry location

Download Full Specs Here :

NYY

Copper Conductor, PVC Insulated and PVC Outer Sheathed

Ref. Standard           :

SNI IEC 60502-1
SPLN 43-1

Construction            :

1 Copper Conductor
2. PVC Insulated
3. PVC Inner sheathed            ( for Multicore)
4. PVC Outer Sheathed

Size range                :

1 x (1.5~500) mm²
2 x (1.5 ~ 150)mm²
3-4 x (1.5~300) mm²
5 x (1.5~50) mm²
7 – 61 core

Application               :

Indoor and outdoor installation or for laying in the ground where is no mechanical damage sustained

Download Full Specs Here :

NYY 4 cores

Download Full Specs Here :
